Tacoma Plate Front Bumper / 3rd Gen / 2016-2023

Plated Front Bumper – 2016–2023 Toyota Tacoma

Built for Strength and Off-Road Performance

Upgrade your 2016–2023 Toyota Tacoma with a plated front bumper engineered for rugged protection and serious off-road performance. Made from premium U.S.-sourced steel, this bumper combines durability, clearance, and industry-leading weld quality to deliver a product you can trust on the trail.

Lighting Versatility

• Integrated side-wing light mounts fit Baja Designs Squadron, S2, and similar pods
• Center mount designed for a 30” single-row light bar
• Finished with a flush-mounted mesh detail panel in the bumper wings for added style

Winch-Ready Design

• Integrated winch mount supports 10K–12K winches (control box relocation may be required on some models)
• Recessed fairlead mount built into a ¼” aluminum skid plate
• Skid plate secured with 5/16” stainless hardware for long-term reliability

Recovery You Can Count On

• 1” billet steel D-rings, fully welded front and back
• Works with ¾” shackles and ⅞” pins
• Provides strong, dependable recovery points for off-road recovery situations

Frame Support & Compatibility

• Includes frame support brackets that mount through the frame (not on top) for superior reinforcement
• Compatible with aftermarket shock reservoirs from King, Fox, and ADS

Finish & Shipping

• Ships RAW steel (not powder coated)
• Professional finishing is strongly recommended before installation

Specs

• Weight: 118 lbs
• Materials: 3/16" steel construction, 1/4" aluminum skid plate, 1 3/4" x .120 wall DOM tubing
• Winch Mount: Fits 10K-12K winches (control box relocation may be necessary)
• Light Compatibility: Center 30" S8 single-row light bar; side mounts fit Squadron or S2 lights
• Fairlead Mount: Recessed into skid plate
• D-Ring Mounts: 1" billet steel, fully welded
• Shackles: Designed for 3/4" shackles with 7/8" pin
• Frame Supports: Included (mount through the frame, $180 value)
• Skid Plate Compatibility: Works with TRD skid plates
• Finish: Ships raw
• Bull Bar Options: Low-height (not TSS compatible); Mid-height with 1.5" x .120 side support tubes (TSS compatible); Full-height with 1.5" x .120 side support tubes (TSS compatible)

• Weight: 118 lbs
• Materials:3/16” steel construction¼” aluminum skid plate1 ¾” x .120 wall DOM tubing
• Winch Mount: Fits 10K–12K winches (control box relocation may be necessary)
• Light Compatibility:Center: 30” S8 single-row light barSide mounts: Squadron or S2 lights
• Fairlead Mount: Recessed into skid plate
• D-Ring Mounts: 1” billet steel, fully welded
• Shackles: Designed for ¾” shackles with 7/8” pin
• Frame Supports: Included (mount through the frame, $180 value)
• Skid Plate Compatibility: Works with TRD skid plates
• Finish: Ships raw
• Bull Bar Options:Low-height (not TSS compatible)Mid-height with 1.5” × .120 side support tubes (TSS compatible)Full-height with 1.5” × .120 side support tubes (TSS compatible)

Estimated lead time: 8-10 weeks

Note: Bumpers are made to order and can not be canceled after production begins.
